Model

ST5381TQZCZ

Chasis NO.

ZZ1317N4667C

Wheel base

4600+1350

Gear box

HW19710

Tire:

12.00R20, 11 pcs

Max. Drive speed

102 (km/h)

Total Mass Fully Loaded

31000(kg)

Fuel consumption (empty load)

33

Fuel consumption(L/100km) (full load)

36

Trailer Boom:

Max.Loading Mass(kg): 30000

Rating Mass of Winch (KN): 150*2

Max.Lifting mass(kg):

12000

Lifting arm:

Max.Lifting with supporting leg mass(kg): 20000

Max.Lifting with supporting leg mass(kg): 20000

Max.Lifting mass when extended(kg): 7000

Effective Length(mm):3775

Rated Towing Mass(kg):38000
