Model

HXF5280GXFPM120/HW Foam fire truck

Cabin

Red color two rows cabin

Engine

Sinotruk 400hp

Gearbox

Sinotruk 10 gears gearbox

Tanker

Tanker volume 12cbm , Welded with high quaIi\y carbon steel frame, one manhole cover , with quick locking and opening device one
pc level indicator, one drain outlet stainless steel spherical valve, 2 water filling inlets

Total mass

27000kg

Curb weight

15150kg

Dimensions

9670mm• 2500mm• 3565mm

Passengers

2+4

Front /rear suspension

1500mm/2495mm

Wheelbase

4600mm,5600mm

Front axle

VGD95 9500kg

Drive axle

HC16*2 16000kg*2

Maximum speed

95km/h

Chassis brand

Howo brand

Tyre specification

315/80R22.5,12.00R20,12.00-20

Leaf spring number

10/12

Front track

2022mm , 2041mm

Rear track

1830mm

Omission standard

GB17C91—2005 Euro 2, GB3847—2005

Engine model

WP12.400E201

Displacement (L)

11.6
