Vehicle Main Dimensions

Overall dimensions (L x W x H)mm

6800x2496x3668

Wheel base  (mm)

3200+1400

Wheel track  (front/rear) (mm)

2022/1830

Approach/Departure angle(°)

16/20

Weight in KGS

Tare Weight

9260

Loading Capacity

25000

Front axles loading capacity

1x7000

Rear axles loading capacity

2x18000

Max. driving speed(km/h)

90

Engine

Brand

Shacman

Model

D12.42

Type

4-stroke direct injection ,  6-cylinder in-line with water cooling, turbo-charging and inter-cooling

Horse Power(HP)

380HP

Emission standard

Euro Ⅲ

Gearbox

HW19712

Clutch

Reinforced diaphragm clutch, diameter 430mm

Steering Gear

ZF 8098, power steering, hydraulic steering with power assistance

Fuel tank (L)

400

Tire

80R22.5 All steel radial tire , 10pieces with one spare

Suspension

Front:  9 semi-elliptic leaf springs with hydraulic telescopic double-action shock absorbers and stabilize

Rear:  14 leaf semi-elliptic leaf springs with bogie springs.

Brakes

Service brake: dual circuit compressed air brake

Parking brake :(emergency brake): spring energy, compressed air operating on rear wheels

Auxiliary brake: engine exhaust valve brake
