Cab

HOWO single row cab, with power steering. Electronic flameout

Driving Type

8x4

Overall dimension(mm)

11000*2500*3300

GVW( kg)

31000kg

Wheelbase(mm)

1300+4500+1350mm

Tire

12.00-20

Gear box

12-speed

Bridge

Front axle

5T/5T

Rear axle

10T/10T

Enging

Model

WD615.69 (Europe 2 emission standard)

Horse power

336HP

Displacement

12597mL

Braking  system

Service Brake

Compressed air brake

Park Brake

Spring energy

Eletric system

24v

Lifting function

Rated. Lifting weight(kg)

10000

Max. Rated towing weight(kg)

5000

Max effective length of boom   (mm)

1750

Extension traveling of boom     (mm)

455

Hoisting function:

Maximum lifting height(mm)

3300

Rated lifting weight (kgs)

1500

Extension traveling of hoisting boom(mm)

1600

Winch function

Quantity (set)

1

Max. Pulling power of winch (kgs)

10000

Length of steel cable(m)

21

Speed of winch (m/min)

8
