Chassis parameters

Chassis model

ZZ1087D3814C180

Chassis brand

SINOTRUK

Overall dimensions

6810X2104X2350mm

Wheel base

3800mm

Front/rear wheel track

1589/1599mm

Front/rear suspension

1160/1850mm

Approach/departure angle

20/21°

Maximum speed

95km/h

Chassis Manufacturer

China National Heavy Duty Truck Group Co.,Ltd

Cab

Configuration

1880 a single row cab.

Color

White, other color is optional

Engine

Model

YN4102QBZL

Emission

Euro 3

Type

4 cylinders, in-line, turbo inter-cooling

Rated power

116hp, rated power speed 3000rpm

Displacement

3760ml

Max.torque

320N.m

Bore x stroke

102X115mm

Tire

Size

7.50R16 steel wire tire

Number

6+1 nos

Fuel tank

120L iron oil tank

Front axle

2.4 tons

Rear axle

4.2 tons

Drive form

4X2

Suspension

Multi leaf springs

Rated voltage

24V, DC

Transmissions

6 speed forward 1 reverse.

Steering device

Power assisted steering

Steering wheel

Left hand drive
