Model

SCS5160GSSZZ4

Brand

SINOTRUK chassis

Cab

2080 mm width, single cabin with a sleeper

Vehicle Description

Overall dimensions(mm)

8400*2420*2750

Effective tank volume

10000L

Max speed (Km/h)

110

Engine Description

Engine model

YC4E160-33

Maximum power

118kw / 160hp

Displacement (lit)

4260

Engine Manufacturer

Yuchai

Chassis Description

Chassis model

ZZ1167G4715C1

Wheel base

4700

F/R track base(mm)

1680/1650

F/R overhang(mm)

1110/2345

Spring plate

8/10+6

Front axle / rear axle

5850/9945kgs

Gear box

MLD 6-speed with over drive

Brake system

oil braking

Operation control system

Power Steering

Electric system

24V

Tyres

9.00R20
