Tank

top color

optinal

Volume

4m3

Tank material and thickness

Part of the tank material、thickness：Q235B carbon steel, 4mm

Head material and thickness: Q235B carbon steel, 5mm

Emergency shut-off valve

Quantity: 1

Material thickness: aluminum alloy

Manhole cover

Type: Aluminum European standard breathing valve with tank port

Quantity: 1 Diameter: 500mm

Oil pump and pipeline

Oil pump, seamless steel pipe; Pump flow: 30m³/h;

Pump pressure: 0.6Mpa;

Speed: 960r/min;

Shaft power: 7.1KW

Pump inlet and outlet

Specification: choose one of DN50/DN65, aluminum alloy

Control method: manual

Refueling reel and fueling gun

15m automatic return reel nozzle

Fuel dispenser

Three gold medals Chinese and English fuel dispenser (with ticketing function)

power takeoff

SDQ51-38PQ1 (flange output) or SDQ51-38LGQ1 (spline output)

Climb the ladder

Welded independent climbing ladder at the end of the tank-movable European style climbing ladder with anti-skid board

Top guard

Protective handrails are installed on both sides of the top of the tank-aluminum alloy folding guardrail

Anti-skid plate installed on the top of the tank-anti-skid walkway

Tube box

Number: 2

Installation position: one on each side of the tank

Specifications: The length of the tube box is the same as the tank body, and the cross section is circular

Water diversion pipe: each pipe box has a built-in water diversion pipe with male and female end joints. The joint model is DN50/DN65.

Fire extinguisher barrel

Material: Q235

Quantity: 2

Fire extinguisher

Specification: 4KG Quantity: 2

exhaust pipe

Rear to front

Electrostatic device

Metal electrostatic plate, electrostatic belt device: 1 each

Subframe

Tank bottom auxiliary beam

Made of Q345 carbon steel plate
