Name

Flatbed semi trailer

Vehicle size

12500mm *2500mm * 1600mm（(According to customer demand)）

Loading capacity

40 Tons

Axle

2 axles/ 3axles/4 axle/ Multi axle, 13 T/16T/20T BPW / FUWA / Fuhua

Suspension

Mechanical suspension(German Type or America Type) or Air suspension

Spring leaf

90(W)mm×13(Thickness)mm×10(Layer)/100mm×12mm×12(specificationcan be Optional)

Wheel base(mm)

5700+1310+1310.

Saddle load

17 Tons

Saddle height

1300mm

Front overhang radius

2150mm

Landing gear

JOST/FUWA/Yahua brand 28T(two speed or single speed)

Top speed

90(km/h)

Brake system

Dual Line braking system

Valve

WABCO/KANGJIAN valve

Tool box

1set standard tool box( waterproof type)

Light

Tail lamp with turn signal, brake light & reflector, side lamp etc

Shipping Terms

By bulk cargo carrier, RORO or 40HQ container
