VOLVO EC480DL EXCAVATOR

Engine

D13F

Rated power(kw/rpm)

270/1800

Maximum torque(N.m)

1800/1400

Displacement(L)

12.8

Number of cylinder

6

Machine working weight(kg)

47300-53100

Tonnage(ton)

48

Bucket capacity(m³)

1.77-3.8

Swing speed（rpm）

8.8

Swing torque(Nm)

166.3

Walking speed(km/h)

3.1/5.1

Shipping size(mm)

11630*3340*3257

Maximum digging radius(mm)

10930

Maximum excavation depth(mm)

6580

Maximum excavation highth(mm)

10600

Fuel tank(L)

685
