Product Parameters
Performance Parameters of Machine | ||
Specification | ||
Overall working weight | t | 21.3 |
Bucket capacity | m³ | 1.0-1.1 |
Engine | ||
Brand |
|
Cummins |
Model |
|
QSB7 |
Type |
|
4-stroke, water cooling and direct injection |
Power | kW/rpm | 124/2050 |
Max. torque | Nm/rpm | 658/1200 |
Displacement | L | 6.7 |
Hydraulic System | ||
Type of primary pump |
|
Variable displacement piston pump x2 |
Max. discharge of primary pump | L/min | 2x240 |
System pressure | MPa | 31.4/34.3 |
Type of pilot pump |
|
Gear pump x 1 |
Max. discharge of pilot pump | L/min | 21 |
Pressure of pilot pump | MPa | 3.9 |
Performance | ||
Slewing speed | rpm | 11.8 |
Traveling speed | km/h | 5.2/3.3 |
Gradeability | o | 35 |
Track width | mm | 600 |
Ground specific pressure | kPa | 46 |
Capacity of Oil Tank | ||
Capacity of fuel tank | L | 370 |
Capacity of hydraulic oil tank | L | 250 |
